Every figure below comes from production testing. Items still awaiting third-party confirmation are marked.
| Parameter | Value | Source |
|---|---|---|
| Material | High-tenacity polyester (PET), warp-knitted | Manufacturer data |
| Coating | Flame-retardant and anti-static polymer | Manufacturer data |
| Strand diameter | 3.0 mm (elliptical section) | Factory record |
| Single-strand break load | 2746 N | National report 2025-004 |
| Width tensile strength | 102 kN/m | Grade designation |
| Elongation at break | 20.6 % | Factory record |
| Mesh aperture | 50 × 50 mm | Grade designation |
| Area weight | 0.8 kg/m² | Factory record |
| Flame time | ≤ 2.9 s burning, ≤ 2.2 s afterglow | Factory record |
| Surface resistance | — Ω | Third-party pending |
| Design service life | 20 years | Design target |
| Roll widths | 1.3 – 2.0 m | Confirmed range |
| Roll lengths | 10 / 20 / 40 / 50 m | Format range |
| Colour | Chestnut brown-red (others to order) | Factory record |
Backed by an issued test document
Factory self-check record
Awaiting third-party confirmation
Illustration, not a test photograph. Break load is measured on the strand; 102 kN/m is the per-metre rating of the finished net, listed above as awaiting third-party confirmation.
Other widths and roll lengths can be produced to order. Send your run dimensions and we will calculate the roll count, allowing for overlap and wastage.
Widths between 1.3 m and 2.0 m, and roll lengths from 10 m upward, can be produced to order. Fixed production runs apply, so lead time grows with deviation from the standard formats.
